Extended Data Fig. 1: Spinal injection sites of adeno-associated viruses for nuclear labelling.

Recombinant AAVs were injected into multiple segments centring on the cervical and lumbar spinal cord of P42 C57BL/6J mice. Mice were euthanized 2 weeks later at P56. a-c, Representative horizontal (i.e., dorsal-ventral longitudinal) sections of spinal cords injected with AAV2/2-H2B into cervical levels 4-6 (C4-6) and lumbar levels 2-4 (L2-4). AAV2/2-H2B does not retrogradely label neurons and therefore labels cells only local to spinal injection sites. b and c are zoom-in of dashed boxed in a. d-f, Representative horizontal sections of spinal cords injected with AAV2/retro-H2B into C4-6 and L2-4. AAV2/retro-H2B, the viral vector used to retrogradely label spinal projecting neurons, has retrograde labeling capability and therefore the spinal injection sites depict both locally transduced cells and retrogradely labelled intraspinal projection neurons (i.e., propriospinal neurons). e and f are zoom-in of dashed boxed in d. g-h, Representative coronal sections of (g) cervical and (h) lumbar spinal injection sites labelled by AAV2/retro-H2B demonstrating labeling in ventral horn, dorsal horn, and intermediate zone of the spinal cord grey matter (marked by dashed outline). N = 3 spinal cords were labelled with AAV2/2-H2B and N = 3 spinal cords were labelled with AAV2/retro-H2B to yield representative images shown here. Scale a-f , 1000 µm; scale g-h , 200 µm.
