Figure 3
From: The PSMP-CCR2 interactions trigger monocyte/macrophage-dependent colitis
PSMP was expressed in the colonic inflammatory and adenocarcinoma tissues. PSMP expression was detected in the normal colonic, ulcerative colitis, Crohn’s disease, chronic inflammation, inflammatory polyp and adenocarcinoma via IHC with rabbit anti-PSMP antibody (5 μg/mL), scale bar = 100 μm. The colon specimens of each indicated disease were from 4~10 different patients.
